- Smartstar Control
- Color LCD
- Diagnostic
- Fuel Saving Mode
- Remote Control
ENGINE
Power : 265 kW (350 hp) (Diesel)
- Hopper Vibrator
- Hydraulic Driven Fan
- Betonstar IoT System
- Remote Control (HBC)
- Air Compressor
- High Pressure Cleaning Kit (140 bar )
- Water Pump (67 lpm)
- Water Tank (500 l and Hose 15 m)
HYDRAULIC SYSTEM
Max. hydraulic pressure : 350 bar (5076,32 psi)
PUMPING UNIT
|
Rod Side
|
Theo. Conc. Output (max)
|
: 90 m³/h
|
|
Theo. Conc. Pressure (max)
|
: 92 bar
|
|
Stroke
|
: 23 Stroke / min
|
|
Piston Side
|
Theo. Conc. Output (max)
|
: 56 m³/h
|
|
Theo. Conc. Pressure (max)
|
: 150 bar
|
|
Stroke
|
: 14 Stroke / min
|
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 200 mm
Delivery Cylinders Lenght : 2100 mm
Hopper Capacity : 650 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
