- Hopper Vibrator
- Hydraulic Driven Fan
- Betonstar IoT System
- Remote Control (HBC)
- Air Compressor
- High Pressure Cleaning Kit (140 bar )
PUMPING UNIT
|
PUMPING UNIT
|
BCS 21.90.
|
BCS 14.90
|
|
Rod Side
|
Theo. Conc. Output (max)
|
90 m³/h
|
90 m³/h
|
|
Theo. Conc. Pressure (max)
|
92 bar
|
71 bar
|
|
Stroke
|
23 Stroke / min
|
34 Stroke / min
|
|
Piston Side
|
Theo. Conc. Output (max)
|
56 m³/h
|
61 m³/h
|
|
Theo. Conc. Pressure (max)
|
148 bar
|
106 bar
|
|
Stroke
|
14 Stroke / min
|
23 Stroke / min
|
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 200 mm
Delivery Cylinders Lenght : 2100 mm (BCS 21.90) : 1400 mm (BCS 14.90)
Hopper Capacity : 650 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC Controlled
