GENERAL
Weight : 2100 kg
ENGINE
Power : 44.5 kW (60 hp) (Diesel)
PUMPING UNIT
Theo. Conc. Output(max) : 21 m3/h
Theo. Conc. Pressure(max) : 80 bar
Stroke : 29 Stroke/min
Drive Cylinder Diameter : 80/45 mm
Delivery cylinders diameter : 150 mm
Delivery cylinders stroke : 700 mm
Hopper capacity : 250 L
Hopper outlet diameter : 100 mm
Maximum particle size : 16 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Electric Box : Waterproof and PLC controlled
CONTROL SYSTEM
- Smartstar Control
- Color LCD
- Diagnostic
- Fuel Saving Mode
- Remote Control
OPTIONS
|
High pressure cleaning kit
|
Power
|
: 3.1 kW
|
|
Water pressure
|
: 138 bar
|
|
Water flow
|
: 10.6 L/min
|
|
Hose reel
|
: Automatic hose reel
|
Hopper vibrator
