- Hopper Vibrator
- Hydraulic Driven Fan
- Betonstar IoT System
- Remote Control (HBC)
- Air Compressor
- High Pressure Cleaning Kit (140 bar )
PUMPING UNIT
|
Piston Side
|
Theo. Conc. Output (max)
|
: 70 m³/h
|
|
Theo. Conc. Pressure (max)
|
: 81 bar
|
|
Stroke
|
: 28 Stroke / min
|
|
Rod Side
|
Theo. Conc. Output (max)
|
: 90 m³/h
|
|
Theo. Conc. Pressure (max)
|
: 54 bar
|
|
Stroke
|
: 36 Stroke / min
|
Concrete Valve : S Valve System
Switch-Over Pressure S-Tube : 190 bar
Delivery Cylinders Diameter : 230 mm
Delivery Cylinders Lenght : 1000 mm
Hopper Capacity : 450 l
Hopper Outlet Diameter : 125 mm
Reducer Output Diameter : 150 mm
Switching System : Elect. Magn. Sensor
Lubrication System : Hydraulic (LINCOLN)
Driven by : PTO or Gear Box
Electric Box : Waterproof and PLC Controlled
